GWINSTEK GPT-12004A ELECTRICAL SAFETY ANALYZER AC/DC/IR/GB/CONT. HI-POT

Fully tested: AC, DC, IR, ground bond, and continuity, on both front and rear panel outputs. Excellent condition. Does not include cables or accessories.

Performance:

• ACW: 5 kVAC
• DCW: 6 kVDC
• IR: 50V–1200V (50V steps)
• GB: 3A–30A
• CONT: 100mA

Features:

• Ramp-up time control
• Ramp-down time control
• Safety discharge
• 100 test conditions (MANU mode)
• 100 automatic tests (AUTO mode)
• Over-temperature, over-voltage, and over-current protection
• Pass, Fail, Test, High Voltage, and Ready indicators
• PWM output (90% efficiency, increased reliability)
• Configurable interlock
• Rear panel output

Interface:

• Remote control start/stop interface terminal
• RS232/USB interface for programming
• Optional GPIB interface for programming
• Signal I/O port for pass/fail/test monitoring and start/stop/interlock control
