IMADA ACT-220 AUTOMATIC WIRE CRIMP TESTER 220 X 0.1 LBF

Imada

SKU:
T191906
IMADA ACT-220 AUTOMATIC WIRE CRIMP TESTER 220 X 0.1 LBF
Same Day Shipping on Rush Orders
Next day air orders ship same day, cut off time 2 PM MST
30-Day Guarantee - See Details
Condition
This is a new item, with the original packaging and includes a 30 day warranty.
$999.99
Request a Quote
Make an Offer

Description

  • Resolution: 0.1 lbf, 1N, 0.1 kgf
  • Accuracy: ±0.5% F.S. ±1 digit
  • Force Units: lbf, N, kgf (selectable)
  • Overload Rating Approx: 150% F.S.
  • Speed Ranges: 10/25/50/100 mm/min or 0.5, 1.0, 2.0, 4.0 in/min (Selectable)
  • Hold Duration: up to 999 seconds in 1 second increments
  • Stroke: Approx. 50mm
  • Sample Diameters: 12 slots, 1 to 8mm
  • Sample Length: 100mm (4") or more
  • Test Modes: BREAK (destructive)/KEEP (non-destructive) modes
  • Test Profiles: Saves up to 26 patterns (A to Z)
  • Internal Memory: 1500 data
  • Outputs: USB/RS232C (for printer output)/Judgment signal (OK/NG)
  • Operating Conditions: 0° to 40° Celsius, 20 to 80%RH
  • Standards: ACT-220 meets test conditions of wire crimp test standards. Review the details of the following standards: UL 486A-486B, ASTM B913, ANSI/EIA-364-38B, MIL-DTL-22520G, NASA-STD-8739.4

Extra Information

Brand:
Imada
Model Part Number:
ACT-220
Shipping Weight:
32 LBS
Shipping Dimensions:
15 (in) × 26 (in) × 13 (in)
